2Way 3Way 4Way Splitter

2Way 3Way 4Way Splitter
CategoriesIndoor Splitter Tap
AlbumView larger image
BrandWEIMAI CABLE
FOB portNingbo/ Shanghai
Terms of PaymentL/C, D/A, D/P, T/T, Western Union, MoneyGram
Download DOC
Update Time2019-06-17
Detail Information

China Manufacturer Supplier Made in China

2Way 3Way  4Way  Splitter

Features :
 Zinc alloy die casting shell with nickel plated surface treatment.
★ Adopt complete tin sealed design,shield level:5-1000MHz100dB.
★ two way transmission design.
★ Easy installation, two side holes are used for fixing the main unit.
★ Surface spray-paint treatment, anti-oxidation and no color fading.

ITEMS                     MODEL
InsertionLoss(dB)Frequency Range(MHz)2Way3Way4Way
 5-10 MHz≤3.5≤5.7≤6.8
 10-50 MHz≤3.6≤5.5≤7.0
 50-750 MHz≤3.8≤6.2≤7.6
 750-1000 MHz≤4.0≤6.5≤8.0
 5-10 MHz≥25≥22≥27
Isolation (dB)10-50 MHz≥28≥25≥28
 50-750 MHz≥28≥25≥28
 750-1000 MHz≥25≥22≥25
 5-10 MHz≥16≥16≥16
Return Loss(dB)10-50 MHz≥18≥18≥18
 50-750 MHz≥18≥18≥18
 750-1000 MHz≥16≥16≥16
